- Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
- A cylindrically shaped socket head cap screw is considered the strongest of all head styles.
- An internal hex socket drive is also known as an Allen drive.
- Alloy steel fasteners are significantly stronger than standard low carbon steel fasteners.
- Diameter (Nominal): 1/4"
- Thread Pitch: 20
- Diameter (Dimension): 0.25"
- Diameter (Minimum): 0.2435"
- Diameter (Maximum): 0.25"
- Length (Nominal): 7/8"
- Thread Length (Nominal): 0.875"
- Drive Recess Size: 3/16"
- Drive Recess Width: 0.188"
- Drive Recess Depth: 0.12"
- Head Diameter: 0.375"
- Head Diameter (Minimum): 0.354"
- Head Diameter (Maximum): 0.375"
- Head Height, Overall: 0.25"
- Head Height, Overall (Minimum): 0.244"
- Head Height, Overall (Maximum): 0.25"
- Category: Socket Head Cap Screws
- System of Measurement: Inch
- Brand: Aspen Fasteners
- Head Style: Cylindrical Head
- Drive Style: Hex Socket Drive
- Threading: Thread Class 3A
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Alloy Steel
- Material Processes: Heat Treated
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: ASME/ANSI B18.3-2002 and ASTM A574
