- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- 18-8 stainless steel is functionally interchangeable with type 304 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): #8
- Thread Pitch: 32
- Diameter (Dimension): 0.164"
- Length (Nominal): 1-1/2"
- Thread Length (Nominal): 1.500"
- Drive Recess Size: #2
- Drive Recess Width: 0.175"
- Drive Recess Depth (Minimum): 0.071"
- Drive Recess Depth (Maximum): 0.097"
- Head Diameter (Minimum): 0.306"
- Head Diameter (Maximum): 0.322"
- Head Height, Overall (Minimum): 0.105"
- Head Height, Overall (Maximum): 0.115"
- Head Radius: 0.015"
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Inch
- Brand: Aspen Fasteners
- Form and Design: Thread-Locking Patch
- Head Style: Pan Head
- Drive Style: Cruciform Recess Drive
- Drive Detail: Phillips Type H
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: 18-8 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
Product UPC Code:
698435744455
- Coating:
- Uncoated
- Material Grade:
- 18-8 Stainless Steel
- Material:
- Stainless Steel
- Thread Direction:
- Right-Hand Thread
- Thread Length:
- Full Thread
- Order:
- Machine Thread Fasteners
- Shop by System of Measurement:
- Inch
- Shop by Material:
- Stainless Steel
- Drive Detail:
- Phillips Type H
- Product Class:
- Externally Threaded Fasteners
- Length (Nominal):
- 1-1/2"
- Thread Pitch:
- 32
- Drive Style:
- Cruciform Recess Drive
- Head Style:
- Pan Head
- Form and Design:
- Thread-Locking Patch
- Diameter (Nominal):
- #8
- Category:
- Machine Screws
- System of Measurement:
- Inch
- Brand:
- Aspen Fasteners
- POS:
- ST324-832X112-000300
- Brand:
- Aspen Fasteners(r)
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ST324-832X112.zip
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product62/ST324-832X112.PDF
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ST324-832X112
- Drive Recess Size:
- #2
- Head Diameter (Minimum):
- 0.306"
- Origin:
- Origin Undefined
- Thread Length (Nominal):
- 1.500"
- Head Height, Overall (Maximum):
- 0.115"
- Head Diameter (Maximum):
- 0.322"
- Diameter (Dimension):
- 0.164"
- Head Height, Overall (Minimum):
- 0.105"
- Drive Recess Depth (Maximum):
- 0.097"
- Drive Recess Depth (Minimum):
- 0.071"
- Drive Recess Width:
- 0.175"
