- Also known as clevis pin spacing washers, used to adjust the grip length of the pin.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M11
- Diameter (Dimension): 11mm
- Inside Diameter (Nominal): 11mm
- Inside Diameter (Minimum): 11mm
- Inside Diameter (Maximum): 11.1mm
- Outside Diameter (Nominal): 22mm
- Outside Diameter (Minimum): 21.48mm
- Outside Diameter (Maximum): 22mm
- Thickness (Nominal): 3mm
- Thickness (Minimum): 2.7mm
- Thickness (Maximum): 3.3mm
PRODUCT ATTRIBUTES- Category: Flat Washers for Clevis Pins
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Form and Design: Not Chamfered
- Material: Steel
- Coating: Uncoated
- Standards and Specifications: DIN 1440 / ISO 8738
Product UPC Code:
692559763668
- Inside Diameter (Nominal):
- 11mm
- System of Measurement:
- Metric
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product82/ME358-11.PDF
- Standards and Specifications:
- DIN 1440 / ISO 8738
- Thickness (Maximum):
- 3.3mm
- Outside Diameter (Nominal):
- 22mm
- Shop by System of Measurement:
- Metric
- Product Class:
- Washers
- Order:
- Flat Washers
- Thickness (Nominal):
- 3mm
- Outside Diameter (Maximum):
- 22mm
- Outside Diameter (Minimum):
- 21.48mm
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME358-11
- Category:
- Flat Washers for Clevis Pins
- Thickness (Minimum):
- 2.7mm
- Shop by Material:
- Steel
- Material:
- Steel
- Diameter (Dimension):
- 11mm
- Inside Diameter (Maximum):
- 11.1mm
- Coating:
- Uncoated
- Inside Diameter (Minimum):
- 11mm
- Diameter (Nominal):
- M11
- Form and Design:
- Not Chamfered
- Brand:
- Aspen Fasteners
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME358-11.zip
- POS:
- ME358-11-00300
