- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M2
- Thread Pitch: 0.4
- Diameter (Dimension): 2mm
- Length (Nominal): 3mm
- Thread Length (Nominal): 3mm
- Head Diameter: 6mm
- Head Diameter (Minimum): 5.64mm
- Head Diameter (Maximum): 6mm
- Head Height, Overall: 1.2mm
- Head Height, Overall (Minimum): 1.08mm
- Head Height, Overall (Maximum): 1.32mm
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Large Pan Head
- Drive Style: Slotted Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: 303 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: DIN 921
Product UPC Code:
692559690896
- Head Diameter (Minimum):
- 5.64mm
- Shop by System of Measurement:
- Metric
- Shop by Material:
- Stainless Steel
- Product Class:
- Externally Threaded Fasteners
- Order:
- Machine Thread Fasteners
- Category:
- Machine Screws
- System of Measurement:
- Metric
- Head Height, Overall:
- 1.2mm
- Brand:
- Aspen Fasteners
- Head Style:
- Large Pan Head
- Drive Style:
- Slotted Drive
- Head Height, Overall (Maximum):
- 1.32mm
- Thread Direction:
- Right-Hand Thread
- Head Height, Overall (Minimum):
- 1.08mm
- Material:
- Stainless Steel
- Material Grade:
- 303 Stainless Steel
- Coating:
- Uncoated
- Standards and Specifications:
- DIN 921
- Diameter (Nominal):
- M2
- Diameter (Dimension):
- 2mm
- Thread Pitch:
- 0.4
- Head Diameter (Maximum):
- 6mm
- Length (Nominal):
- 3mm
- Thread Length:
- 3mm
- Head Diameter:
- 6mm
- Origin:
- Origin Undefined
- Thread Length (Nominal):
- 3mm
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME531-204X3
- POS:
- ME531-204X3-000200
