- A4 stainless steel is functionally equivalent to 316 grade and is also known as "marine grade".
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- The nominal diameter is the bolt size to use for this flat washer.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M20
- Diameter (Dimension): 20mm
- Inside Diameter (Nominal): 21mm
- Inside Diameter (Minimum): 21mm
- Inside Diameter (Maximum): 21.33mm
- Outside Diameter (Nominal): 34mm
- Outside Diameter (Minimum): 33.38mm
- Outside Diameter (Maximum): 34mm
- Thickness (Nominal): 3mm
- Thickness (Minimum): 2.7mm
- Thickness (Maximum): 3.3mm
PRODUCT ATTRIBUTES- Category: Standard Flat Washers
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Form and Design: Small Outside Diameter
- Material: Stainless Steel
- Material Grade: A4 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 433 / ISO 7092
