- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- Pan head screws are also known as raised cheese head screws.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M6
- Thread Pitch: 1.0
- Diameter (Dimension): 6mm
- Length (Nominal): 12mm
- Thread Length (Nominal): 9mm
- Head Diameter: 13mm
- Head Diameter (Minimum): 12.73mm
- Head Diameter (Maximum): 13mm
- Head Height, Overall: 3.1mm
- Head Height, Overall (Minimum): 2.95mm
- Head Height, Overall (Maximum): 3.25mm
- Shoulder Diameter: 8mm
- Shoulder Diameter (Minimum): 7.964mm
- Shoulder Diameter (Maximum): 8mm
- Shoulder Length: 12mm
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Form and Design: Shoulder Under Head
- Head Style: Pan Head
- Drive Style: Slotted Drive
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: 303 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: DIN 923
Product UPC Code:
692559678634
- Head Diameter (Maximum):
- 13mm
- Shoulder Diameter:
- 8mm
- Standards and Specifications:
- DIN 923
- Product Class:
- Externally Threaded Fasteners
- Thread Pitch:
- 1.0
- Material:
- Stainless Steel
- Shop by Material:
- Stainless Steel
- Shop by System of Measurement:
- Metric
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME516-610X12
- Thread Length (Nominal):
- 9mm
- Brand:
- Aspen Fasteners
- Drive Style:
- Slotted Drive
- Head Style:
- Pan Head
- Shoulder Diameter (Maximum):
- 8mm
- Category:
- Machine Screws
- Head Diameter (Minimum):
- 12.73mm
- Diameter (Nominal):
- M6
- Order:
- Machine Thread Fasteners
- Head Height, Overall:
- 3.1mm
- Head Diameter:
- 13mm
- System of Measurement:
- Metric
- Length (Nominal):
- 12mm
- Form and Design:
- Shoulder Under Head
- Head Height, Overall (Maximum):
- 3.25mm
- Shoulder Length:
- 12mm
- Shoulder Diameter (Minimum):
- 7.964mm
- Coating:
- Uncoated
- Head Height, Overall (Minimum):
- 2.95mm
- Diameter (Dimension):
- 6mm
- Material Grade:
- 303 Stainless Steel
- Thread Direction:
- Right-Hand Thread
- Origin:
- Origin Undefined
- POS:
- ME516-610X12-000050
