- Holds an object in place via friction between the point of the screw and the fastened material.
- Headless set screws are also known as blind screws or grub screws.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Set screws are designed to be used under compressive stress only.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M6
- Thread Pitch: 1.0
- Diameter (Dimension): 6mm
- Length (Nominal): 25mm
- Thread Length (Nominal): 25mm
- Point Width: 1.5mm
- Slot Depth (Minimum): 1.6mm
- Slot Depth (Maximum): 2mm
- Slot Width (Nominal): 1mm
- Slot Width (Minimum): 1.06mm
- Slot Width (Maximum): 1.2mm
PRODUCT ATTRIBUTES- Category: Set Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Headless
- Drive Style: Slotted Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Point: Cone Point
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: DIN 553 / ISO 7434
Product UPC Code:
692559479194
- Thread Length (Nominal):
- 25mm
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME414-610X25.zip
- Head Style:
- Headless
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product49/ME414-610X25.PDF
- Slot Depth (Maximum):
- 2mm
- Slot Depth (Minimum):
- 1.6mm
- Slot Width (Maximum):
- 1.2mm
- Thread Length:
- Full Thread
- Thread Pitch:
- 1.0
- Slot Width (Nominal):
- 1mm
- Material Grade:
- A2 Stainless Steel
- Drive Style:
- Slotted Drive
- Origin:
- Origin Undefined
- Coating:
- Uncoated
- Thread Direction:
- Right-Hand Thread
- Shop by Material:
- Stainless Steel
- Category:
- Set Screws
- Material:
- Stainless Steel
- System of Measurement:
- Metric
- Length (Nominal):
- 25mm
- Point:
- Cone Point
- Diameter (Nominal):
- M6
- Brand:
- Aspen Fasteners
- Diameter (Dimension):
- 6mm
- Product Class:
- Externally Threaded Fasteners
- Order:
- Machine Thread Fasteners
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME414-610X25
- Slot Width (Minimum):
- 1.06mm
- Shop by System of Measurement:
- Metric
- Standards and Specifications:
- DIN 553 / ISO 7434
- Point Width:
- 1.5mm
- POS:
- ME414-610X25-000400
