- Holds an object in place via friction between the point of the screw and the fastened material.
- Headless set screws are also known as blind screws or grub screws.
- An internal hex socket drive is also known as an Allen drive.
- Class 45H steel is an alloy steel, quenched and tempered to Rockwell hardness HRC C45-C53.
- Set screws are designed to be used under compressive stress only.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M8
- Thread Pitch: 1.25
- Diameter (Dimension): 8mm
- Length (Nominal): 50mm
- Thread Length (Nominal): 50mm
- Drive Recess Size: 4mm
- Drive Recess Depth: 5mm
- Point Length: 4mm
- Point Length (Minimum): 4mm
- Point Length (Maximum): 4.3mm
- Point Width: 5.5mm
- Point Width (Minimum): 5.2mm
- Point Width (Maximum): 5.5mm
PRODUCT ATTRIBUTES- Category: Set Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Headless
- Drive Style: Hex Socket Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Point: Full Dog Point
- Material: Steel
- Material Grade: Class 45H Steel
- Material Processes: Quenched and Tempered
- Coating: Uncoated
- Coating Color: Black
- Origin: Origin Undefined
- Standards and Specifications: DIN 915 / ISO 4028
Product UPC Code:
692559470894
- Point Width:
- 5.5mm
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME269-8125X50.zip
- Point Width (Minimum):
- 5.2mm
- Point Length (Maximum):
- 4.3mm
- Thread Length (Nominal):
- 50mm
- Product Class:
- Externally Threaded Fasteners
- Shop by Application:
- Socket Products
- Thread Pitch:
- 1.25
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product66/ME269-8125X50.PDF
- Shop by System of Measurement:
- Metric
- Order:
- Machine Thread Fasteners
- Point:
- Full Dog Point
- Origin:
- Origin Undefined
- Category:
- Set Screws
- Coating:
- Uncoated
- Length (Nominal):
- 50mm
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME269-8125X50
- Coating Color:
- Black
- Drive Style:
- Hex Socket Drive
- Point Length (Minimum):
- 4mm
- Brand:
- Aspen Fasteners
- Diameter (Nominal):
- M8
- Drive Recess Depth:
- 5mm
- Material Processes:
- Quenched and Tempered
- Drive Recess Size:
- 4mm
- Material Grade:
- Class 45H Steel
- Standards and Specifications:
- DIN 915 / ISO 4028
- Thread Direction:
- Right-Hand Thread
- Point Width (Maximum):
- 5.5mm
- Diameter (Dimension):
- 8mm
- System of Measurement:
- Metric
- Material:
- Steel
- Thread Length:
- Full Thread
- Point Length:
- 4mm
- Shop by Material:
- Steel
- Head Style:
- Headless
- POS:
- ME269-8125X50-00050
