- Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
- A cylindrically shaped socket head cap screw is considered the strongest of all head styles.
- An internal hex socket drive is also known as an Allen drive.
- Alloy steel fasteners are significantly stronger than standard low carbon steel fasteners.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): 1"
- Thread Pitch: 14
- Diameter (Dimension): 1"
- Diameter (Minimum): 0.9886"
- Diameter (Maximum): 1"
- Length (Nominal): 3-1/2"
- Thread Length (Nominal): 2.5"
- Drive Recess Size: 3/4"
- Drive Recess Width: 0.75"
- Drive Recess Depth: 0.495"
- Head Diameter: 1.5"
- Head Diameter (Minimum): 1.476"
- Head Diameter (Maximum): 1.5"
- Head Height, Overall: 1"
- Head Height, Overall (Minimum): 0.988"
- Head Height, Overall (Maximum): 1"
PRODUCT ATTRIBUTES- Category: Socket Head Cap Screws
- System of Measurement: Inch
- Brand: Aspen Fasteners
- Form and Design: Semi-Standard
- Head Style: Cylindrical Head
- Drive Style: Hex Socket Drive
- Pitch: UNS Fine Thread
- Thread Length: Part Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Alloy Steel
- Material Processes: Heat Treated
- Coating: Oxidized
- Coating Color: Black
- Origin: Origin Undefined
- Standards and Specifications: ASME/ANSI B18.3-2002 and ASTM A574
Product UPC Code:
698435540620
