- A drill shaped point is used to cut through thick and hard material without needing a pilot hole.
- Flat countersunk head screws sit flush with the surface of the material they are inserted into.
- 18-8 stainless steel is functionally interchangeable with type 304 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): #10
- Thread Pitch: 16
- Diameter (Dimension): 0.1875"
- Length (Nominal): 4"
PRODUCT ATTRIBUTES- Category: Self-Drilling Screws
- System of Measurement: Inch
- Brand: Aspen Fasteners®
- Head Style: Flat Countersunk Head
- Head Style Detail: 82 Degree Countersink
- Drive Style: Cruciform Recess Drive
- Drive Detail: Phillips Type H
- Thread Direction: Right-Hand Thread
- Point: Self-Drilling Point
- Material: Stainless Steel
- Material Grade: 18-8 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: ASME B18.6.3 and SAE J78
Product UPC Code:
692559741581
- Drive Style:
- Cruciform Recess Drive
- Drive Detail:
- Phillips Type H
- Length (Nominal):
- 4"
- Thread Pitch:
- 16
- Diameter (Dimension):
- 0.1875"
- Diameter (Nominal):
- #10
- Standards and Specifications:
- ASME B18.6.3 and SAE J78
- Coating:
- Uncoated
- Material Grade:
- 18-8 Stainless Steel
- Material:
- Stainless Steel
- Point:
- Self-Drilling Point
- Thread Direction:
- Right-Hand Thread
- Shop by System of Measurement:
- Inch
- Shop by Material:
- Stainless Steel
- Product Class:
- Externally Threaded Fasteners
- Order:
- Thread Cutting Fasteners
- Category:
- Self-Drilling Screws
- System of Measurement:
- Inch
- Brand:
- Aspen Fasteners
- Head Style:
- Flat Countersunk Head
- Head Style Detail:
- 82 Degree Countersink
- POS:
- ST038-1016X4-000400
