- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- 18-8 stainless steel is functionally interchangeable with type 304 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): 3/8"
- Thread Pitch: 16
- Diameter (Dimension): 0.375"
- Length (Nominal): 2"
- Thread Length (Nominal): 2.000"
- Across Flats (Minimum): 0.551"
- Across Flats (Maximum): 0.562"
- Head Height, Overall (Minimum): 0.270"
- Head Height, Overall (Maximum): 0.295"
- Flange Diameter (Minimum): 0.037"
- Flange Diameter (Maximum): 0.063"
- Flange Thickness (Minimum): 0.720"
- Flange Thickness (Maximum): 0.780"
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Inch
- Brand: Aspen Fasteners
- Head Style: Hex Indented Washer Head
- Drive Style: External Hex Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: 18-8 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: ASME B18.6.3
Product UPC Code:
698435644311
- System of Measurement:
- Inch
- Standards and Specifications:
- ASME B18.6.3
- Thread Length:
- Full Thread
- Coating:
- Uncoated
- Material Grade:
- 18-8 Stainless Steel
- Material:
- Stainless Steel
- Thread Direction:
- Right-Hand Thread
- Thread Pitch:
- 16
- Diameter (Nominal):
- 3/8"
- Shop by System of Measurement:
- Inch
- Shop by Material:
- Stainless Steel
- Product Class:
- Externally Threaded Fasteners
- Order:
- Machine Thread Fasteners
- Category:
- Machine Screws
- Brand:
- Aspen Fasteners
- Head Style:
- Hex Indented Washer Head
- Drive Style:
- External Hex Drive
- Length (Nominal):
- 2"
- Origin:
- Origin Undefined
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ST104-3816X2
- POS:
- ST104-3816X2-000150
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ST104-3816X2.zip
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product46/ST104-3816X2.PDF
- Head Height, Overall (Minimum):
- 0.270"
- Diameter (Dimension):
- 0.375"
- Across Flats (Maximum):
- 0.562"
- Flange Diameter (Minimum):
- 0.037"
- Across Flats (Minimum):
- 0.551"
- Thread Length (Nominal):
- 2.000"
- Flange Thickness (Maximum):
- 0.780"
- Head Height, Overall (Maximum):
- 0.295"
- Flange Diameter (Maximum):
- 0.063"
- Flange Thickness (Minimum):
- 0.720"
