- Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
- Button head screws have a wider bearing surface and maintain a low head profile.
- 18-8 stainless steel is functionally interchangeable with type 304 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): #8
- Thread Pitch: 32
- Diameter (Dimension): 0.164"
- Length (Nominal): 3/8"
- Thread Length (Nominal): 0.375"
- Drive Recess Size: T15
- Drive Recess Width: 0.132"
- Drive Recess Depth: 0.04"
- Head Diameter (Minimum): 0.298"
- Head Diameter (Maximum): 0.312"
- Head Height, Overall (Minimum): 0.077"
- Head Height, Overall (Maximum): 0.087"
PRODUCT ATTRIBUTES- Category: Socket Head Cap Screws
- System of Measurement: Inch
- Brand: Aspen Fasteners
- Head Style: Button Head
- Drive Style: Tamper-Resistant 6Lobe Pin Drive
- Drive Detail: Torx® Generic Alternative
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: 18-8 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
Product UPC Code:
692559802299
