- Hex cap screws are manufactured to tighter tolerances as compared to hex bolts.
- Class 8.8 steel is a tempered medium carbon steel with a minimum tensile strength of 800/mm-2 (Mpa).
- The washer face under the head provides a precision bearing surface.
- The chamfered point improves engagement with a nut or pre-tapped hole.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M12
- Thread Pitch: 1.75
- Diameter (Dimension): 12mm
- Length (Nominal): 35mm
- Thread Length (Nominal): 35mm
- Across Flats (Basic): 19mm
- Across Flats (Minimum): 18.67mm
- Across Flats (Maximum): 19mm
- Head Height, Overall: 7.5mm
- Head Height, Overall (Minimum): 7.32mm
- Head Height, Overall (Maximum): 7.68mm
PRODUCT ATTRIBUTES- Category: Cap Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Hex Head
- Head Style Detail: Washer Face
- Drive Style: External Hex Drive
- Pitch: Coarse Thread
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Point: Chamfered Point
- Material: Steel
- Material Grade: Class 8.8 Steel
- Material Processes: Quenched and Tempered
- Coating: Zinc Plated
- Coating Color: Clear
- Origin: Origin Undefined
- Standards and Specifications: DIN 933 / ISO 4017
