- Sometimes called Frame Bolts as these bolts are commonly used on truck frames.
- Also known as hex flange screws or hex washer bolts.
- Flange under the head acts like a washer to increase the bearing surface and distribute the load.
- Class 8.8 steel is a tempered medium carbon steel with a minimum tensile strength of 800/mm-2 (Mpa).
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M16
- Thread Pitch: 2.0
- Diameter (Dimension): 16mm
- Length (Nominal): 30mm
- Thread Length (Nominal): 30mm
- Across Flats (Basic): 21mm
- Across Flats (Minimum): 20.67mm
- Across Flats (Maximum): 21mm
- Head Height, Overall: 14.4mm
- Flange Diameter: 35mm
- Flange Thickness: 8.6mm
PRODUCT ATTRIBUTES- Category: Flange Bolts
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Hex Flange Head
- Drive Style: External Hex Drive
- Thread Length: Part Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Class 8.8 Steel
- Material Processes: Quenched and Tempered
- Coating: Uncoated
- Standards and Specifications: DIN 6921
Product UPC Code:
692559986531
- Length (Nominal):
- 30mm
- Flange Diameter:
- 35mm
- Across Flats (Basic):
- 21mm
- Standards and Specifications:
- DIN 6921
- Order:
- Machine Thread Fasteners
- Material Grade:
- Class 8.8 Steel
- Material:
- Steel
- Product Class:
- Externally Threaded Fasteners
- Drive Style:
- External Hex Drive
- System of Measurement:
- Metric
- Thread Length (Nominal):
- 30mm
- Thread Pitch:
- 2.0
- Diameter (Nominal):
- M16
- Coating:
- Uncoated
- Category:
- Flange Bolts
- Head Style:
- Hex Flange Head
- Flange Thickness:
- 8.6mm
- Material Processes:
- Quenched and Tempered
- Across Flats (Maximum):
- 21mm
- Head Height, Overall:
- 14.4mm
- Shop by Material:
- Steel
- Shop by System of Measurement:
- Metric
- Across Flats (Minimum):
- 20.67mm
- Thread Length:
- Part Thread
- Diameter (Dimension):
- 16mm
- Brand:
- Aspen Fasteners
- Thread Direction:
- Right-Hand Thread
- POS:
- ME005-1620X30-000050
