- Hex finished nuts are considered the most commonly used hex nuts.
- DIN 934 hex nuts are the most commonly used metric hex nuts.
- Also known as regular hex nuts.
- Class 10 nuts are designed to be used with screws and bolts of property class 10.9 or lower.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M18
- Thread Pitch: 2.5
- Diameter (Dimension): 18mm
- Thread Length (Nominal): 15mm
- Across Flats (Basic): 27mm
- Height (Basic): 15mm
PRODUCT ATTRIBUTES- Category: Hex Finished Nuts
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Drive Style: External Hex Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Class 10 Steel
- Material Processes: Heat Treated, Quenched and Tempered
- Coating: Zinc Plated
- Coating Color: Clear
- Hardness Rating: Rockwell C26-C36
- Standards and Specifications: DIN 934 / ISO 4032
Product UPC Code:
698435164178
- Brand:
- Aspen Fasteners(r)
- System of Measurement:
- Metric
- Diameter (Nominal):
- M18
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product37/ME017-1825.PDF
- Shop by System of Measurement:
- Metric
- Material Grade:
- Class 10 Steel
- Hardness Rating:
- Rockwell C26-C36
- POS:
- ME017-1825-00050
- Diameter (Dimension):
- 18mm
- Across Flats (Basic):
- 27mm
- Thread Direction:
- Right-Hand Thread
- Shop by Material:
- Steel
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME017-1825.zip
- Coating:
- Zinc Plated
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME017-1825
- Coating Color:
- Clear
- Drive Style:
- External Hex Drive
- Thread Length (Nominal):
- 15mm
- Category:
- Hex Finished Nuts
- Height (Basic):
- 15mm
- Thread Length:
- Full Thread
- Order:
- Nuts
- Material Processes:
- Heat Treated, Quenched and Tempered
- Material:
- Steel
- Thread Pitch:
- 2.5
- Standards and Specifications:
- DIN 934 / ISO 4032
- Product Class:
- Internally Threaded Fasteners
