- ISO 14583 formerly referred to the DIN 7985 specification.
- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- A 6-lobe recess is also known as a hexalobular internal drive.
- Pan head screws are also known as raised cheese head screws.
- A4 stainless steel is functionally equivalent to 316 grade and is also known as "marine grade".
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M2
- Thread Pitch: 0.4
- Diameter (Dimension): 2mm
- Length (Nominal): 18mm
- Thread Length (Nominal): 18mm
- Drive Recess Size: T6
- Drive Recess Width: 1.75mm
- Drive Recess Depth (Minimum): 0.63mm
- Drive Recess Depth (Maximum): 0.77mm
- Head Diameter: 4mm
- Head Diameter (Minimum): 3.7mm
- Head Diameter (Maximum): 4mm
- Head Height, Overall: 1.6mm
- Head Height, Overall (Minimum): 1.46mm
- Head Height, Overall (Maximum): 1.6mm
- Head Radius: 3.2mm
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Pan Head
- Drive Style: 6Lobe Drive
- Drive Detail: Torx® Generic Alternative
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: A4 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: ISO 14583
Product UPC Code:
692559687094
- Standards and Specifications:
- ISO 14583
- Material Grade:
- A4 Stainless Steel
- Coating:
- Uncoated
- Diameter (Nominal):
- M2
- Diameter (Dimension):
- 2mm
- Thread Pitch:
- 0.4
- Length (Nominal):
- 18mm
- Thread Length:
- 18mm
- Head Diameter:
- 4mm
- Head Diameter (Minimum):
- 3.7mm
- Head Diameter (Maximum):
- 4mm
- Head Height, Overall:
- 1.6mm
- Head Height, Overall (Minimum):
- 1.46mm
- Head Height, Overall (Maximum):
- 1.6mm
- Shop by System of Measurement:
- Metric
- Shop by Material:
- Stainless Steel
- Product Class:
- Externally Threaded Fasteners
- Order:
- Machine Thread Fasteners
- Category:
- Machine Screws
- System of Measurement:
- Metric
- Brand:
- Aspen Fasteners
- Head Style:
- Pan Head
- Drive Style:
- 6Lobe Drive
- Drive Detail:
- Torx(r) Generic Alternative
- Thread Direction:
- Right-Hand Thread
- Material:
- Stainless Steel
- POS:
- ME526-204X18-003000
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME526-204X18
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME526-204X18.zip
- Drive Recess Width:
- 1.75mm
- Origin:
- Origin Undefined
- Drive Recess Size:
- T6
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product52/ME526-204X18.PDF
- Thread Length (Nominal):
- 18mm
- Drive Recess Depth (Maximum):
- 0.77mm
- Drive Recess Depth (Minimum):
- 0.63mm
