- Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
- Button head screws have a wider bearing surface and maintain a low head profile.
- An internal hex socket drive is also known as an Allen drive.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M2
- Thread Pitch: 0.4
- Diameter (Dimension): 2mm
- Length (Nominal): 20mm
- Thread Length: 20mm
- Drive Size: 1.3mm
- Head Diameter: 3.8mm
- Head Diameter (Minimum): 3.5mm
- Head Diameter (Maximum): 3.8mm
- Head Height, Overall: 1.3mm
- Product Class: Externally Threaded Fasteners
- Order: Machine Thread Fasteners
- Category: Socket Head Cap Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Button Head
- Drive Style: Hex Socket Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: ISO 7380-1
Product UPC Code:
698435874183
- Product Class:
- Externally Threaded Fasteners
- Order:
- Machine Thread Fasteners
- Category:
- Socket Head Cap Screws
- System of Measurement:
- Metric
- Brand:
- Aspen Fasteners
- Head Style:
- Button Head
- Drive Style:
- Hex Socket Drive
- Thread Length:
- Full Thread
- Thread Direction:
- Right-Hand Thread
- Material:
- Stainless Steel
- Material Grade:
- A2 Stainless Steel
- Coating:
- Uncoated
- Standards and Specifications:
- ISO 7380-1
- Diameter (Nominal):
- M2
- Diameter (Dimension):
- 2mm
- Thread Pitch:
- 0.4
- Length (Nominal):
- 20mm
- Thread Length:
- 20mm
- Recess Size:
- 1.3mm
- Head Diameter:
- 3.8mm
- Head Diameter (Minimum):
- 3.5mm
- Head Diameter (Maximum):
- 3.8mm
- Head Height, Overall:
- 1.3mm
