- Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
- Button head screws have a wider bearing surface and maintain a low head profile.
- An internal hex socket drive is also known as an Allen drive.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M2
- Thread Pitch: 0.4
- Diameter (Dimension): 2mm
- Length (Nominal): 4mm
- Thread Length (Nominal): 4mm
- Drive Recess Size: 1.3mm
- Drive Recess Width (Minimum): 1.32mm
- Drive Recess Width (Maximum): 1.36mm
- Drive Recess Depth: 0.6mm
- Head Diameter: 3.8mm
- Head Diameter (Minimum): 3.5mm
- Head Diameter (Maximum): 3.8mm
- Head Height, Overall: 1.3mm
- Head Height, Overall (Minimum): 1.16mm
- Head Height, Overall (Maximum): 1.3mm
- Category: Socket Head Cap Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Button Head
- Drive Style: Hex Socket Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: ISO 7380-1
- Thread Length:
- Full Thread
- Product Class:
- Externally Threaded Fasteners
- Shop by System of Measurement:
- Metric
- Shop by Application:
- Socket Products
- Shop by Material:
- Stainless Steel
- Category:
- Socket Head Cap Screws
- Order:
- Machine Thread Fasteners
- System of Measurement:
- Metric
- Brand:
- Aspen Fasteners
- Head Style:
- Button Head
- Drive Style:
- Hex Socket Drive
- Thread Direction:
- Right-Hand Thread
- Material:
- Stainless Steel
- Material Grade:
- A2 Stainless Steel
- Coating:
- Uncoated
- Standards and Specifications:
- ISO 7380-1
- Diameter (Nominal):
- M2
- Diameter (Dimension):
- 2mm
- Thread Pitch:
- 0.4
- Length (Nominal):
- 4mm
- Thread Length:
- 4mm
- Recess Size:
- 1.3mm
- Head Diameter:
- 3.8mm
- Head Diameter (Minimum):
- 3.5mm
- Head Diameter (Maximum):
- 3.8mm
- Head Height, Overall:
- 1.3mm
- POS:
- ME125-204X4-00800,ME125-204X4-001000
- Brand:
- Aspen Fasteners(r)
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME125-204X4
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product64/ME125-204X4.PDF
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME125-204X4.zip
- Head Height, Overall (Maximum):
- 1.3mm
- Thread Length (Nominal):
- 4mm
- Drive Recess Size:
- 1.3mm
- Drive Recess Width (Minimum):
- 1.32mm
- Drive Recess Depth:
- 0.6mm
- Drive Recess Width (Maximum):
- 1.36mm
- Head Height, Overall (Minimum):
- 1.16mm
- Origin:
- Origin Undefined
-
Description
- Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
- Button head screws have a wider bearing surface and maintain a low head profile.
- An internal hex socket drive is also known as an Allen drive.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M2
- Thread Pitch: 0.4
- Diameter (Dimension): 2mm
- Length (Nominal): 4mm
- Thread Length (Nominal): 4mm
- Drive Recess Size: 1.3mm
- Drive Recess Width (Minimum): 1.32mm
- Drive Recess Width (Maximum): 1.36mm
- Drive Recess Depth: 0.6mm
- Head Diameter: 3.8mm
- Head Diameter (Minimum): 3.5mm
- Head Diameter (Maximum): 3.8mm
- Head Height, Overall: 1.3mm
- Head Height, Overall (Minimum): 1.16mm
- Head Height, Overall (Maximum): 1.3mm
- Category: Socket Head Cap Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Button Head
- Drive Style: Hex Socket Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Origin: Origin Undefined
- Standards and Specifications: ISO 7380-1
-
