- Using receiving holes, dowel pins use friction to hold parts of an assembly together.
- Can be used as pivot pins, hinges, or locating pins.
- Diameter (Nominal): M2
- Diameter (Dimension): 2mm
- Diameter (Minimum): 2.002mm
- Diameter (Maximum): 2.008mm
- Length (Nominal): 18mm
- Ball End Height: 0.3mm
- Chamfer Length: 0.6mm
- Product Class: Pins and Wireforms
- Order: Dowel Pins
- Category: Solid Dowel Pins
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Rounded Ends
- Tolerance: Tolerance m6
- Material: Steel
- Material Processes: Hardened
- Coating: Uncoated
- Hardness Rating: Rockwell C58-C62
- Standards and Specifications: DIN 6325
Product UPC Code:
698435252295
- Coating:
- Uncoated
- Hardness Rating:
- Rockwell C58-C62
- Tolerance:
- Tolerance m6
- Form and Design:
- Rounded Ends
- Brand:
- Aspen Fasteners(r)
- System of Measurement:
- Metric
- Category:
- Solid Dowel Pins
- Order:
- Dowel Pins
- Product Class:
- Pins and Wireforms
- Shop by Material:
- Steel
- Shop by System of Measurement:
- Metric
- Standards and Specifications:
- DIN 6325
- Diameter (Nominal):
- M2
- Diameter (Dimension):
- 2mm
- Diameter (Minimum):
- 2.002mm
- Diameter (Maximum):
- 2.008mm
- Length (Nominal):
- 18mm
- Ball End Height:
- 0.3mm
- Chamfer Length:
- 0.6mm
- Material:
- Steel
- Material Processes:
- Hardened
