- Using receiving holes, dowel pins use friction to hold parts of an assembly together.
- Can be used as pivot pins, hinges, or locating pins.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M20
- Diameter (Dimension): 20mm
- Diameter (Minimum): 20.008mm
- Diameter (Maximum): 20.021mm
- Length (Nominal): 100mm
- Ball End Height: 3mm
- Product Class: Pins and Wireforms
- Order: Dowel Pins
- Category: Solid Dowel Pins
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Rounded Ends
- Tolerance: Tolerance m6
- Material: Stainless Steel
- Material Grade: AISI 303 Stainless Steel (18-8)
- Material Processes: Unhardened
- Coating: Uncoated
- Standards and Specifications: DIN 7 Type A
Product UPC Code:
692559595801
- Material:
- Stainless Steel
- Brand:
- Aspen Fasteners(r)
- Category:
- Solid Dowel Pins
- Order:
- Dowel Pins
- Product Class:
- Pins and Wireforms
- Shop by Material:
- Stainless Steel
- Shop by System of Measurement:
- Metric
- Ball End Height:
- 3mm
- Length (Nominal):
- 100mm
- Diameter (Maximum):
- 20.021mm
- Diameter (Minimum):
- 20.008mm
- Diameter (Dimension):
- 20mm
- Diameter (Nominal):
- M20
- Standards and Specifications:
- DIN 7 Type A
- Coating:
- Uncoated
- Material Processes:
- Unhardened
- Material Grade:
- AISI 303 Stainless Steel (18-8)
- System of Measurement:
- Metric
- Tolerance:
- Tolerance m6
- Form and Design:
- Rounded Ends
