- ISO 14585 formerly referred to the DIN 7981 specification.
- Also known as self-tapping screws, these are mostly used in thin gauge sheet metal applications.
- Pan head screws are also known as raised cheese head screws.
- A 6-lobe recess is also known as a hexalobular internal drive.
- A4 stainless steel is functionally equivalent to 316 grade and is also known as "marine grade".
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M3.5
- Diameter (Dimension): 3.5mm
- Length (Nominal): 16mm
- Thread Length: 16mm
- Recess Size: T2
- Head Diameter: 6.9mm
- Head Height, Overall: 2.6mm
- Product Class: Externally Threaded Fasteners
- Order: Thread Cutting Fasteners
- Category: Self-Tapping Sheet Metal Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Pan Head
- Drive Style: 6Lobe Drive
- Drive Detail: Torx® Generic Alternative
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: A4 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: ISO 14585
Product UPC Code:
692559574233
- System of Measurement:
- Metric
- Coating:
- Uncoated
- Material:
- Stainless Steel
- Thread Direction:
- Right-Hand Thread
- Brand:
- Aspen Fasteners(r)
- Material Grade:
- A4 Stainless Steel
- Standards and Specifications:
- ISO 14585
- Diameter (Nominal):
- M3.5
- Stainless Steel:
- Stainless Steel
- Product Class:
- Externally Threaded Fasteners
- Thread Length:
- Full Thread
- Drive Detail:
- Torx(r) Generic Alternative
- Diameter (Dimension):
- 3.5mm
- Drive Style:
- 6Lobe Drive
- Head Style:
- Pan Head
- Length (Nominal):
- 16mm
- Thread Length:
- 16mm
- Recess Size:
- T2
- Head Diameter:
- 6.9mm
- Head Height, Overall:
- 2.6mm
- Order:
- Thread Cutting Fasteners
- Category:
- Self-Tapping Sheet Metal Screws
