- A drill shaped point is used to cut through thick and hard material without needing a pilot hole.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M3.9
- Diameter (Dimension): 3.9mm
- Length (Nominal): 25mm
- Recess Size: #2
- Head Diameter: 7.5mm
- Head Height, Overall: 2.3mm
- Product Class: Externally Threaded Fasteners
- Order: Thread Cutting Fasteners
- Category: Self-Drilling Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Flat Countersunk Head
- Head Style Detail: 80 Degree Countersink
- Drive Style: Cruciform Recess Drive
- Drive Detail: Phillips Type H
- Thread Direction: Right-Hand Thread
- Point: Self-Drilling Point
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 7504 Type O
Product UPC Code:
692559640587
- Brand:
- Aspen Fasteners(r)
- Diameter (Dimension):
- 3.9mm
- Length (Nominal):
- 25mm
- Recess Size:
- #2
- Head Diameter:
- 7.5mm
- Head Height, Overall:
- 2.3mm
- Material Grade:
- A2 Stainless Steel
- System of Measurement:
- Metric
- Category:
- Self-Drilling Screws
- Material:
- Stainless Steel
- Point:
- Self-Drilling Point
- Order:
- Thread Cutting Fasteners
- Standards and Specifications:
- DIN 7504 Type O
- Coating:
- Uncoated
- Diameter (Nominal):
- M3.9
- Drive Detail:
- Phillips Type H
- Drive Style:
- Cruciform Recess Drive
- Thread Direction:
- Right-Hand Thread
- Head Style Detail:
- 80 Degree Countersink
- Stainless Steel:
- Stainless Steel
- Product Class:
- Externally Threaded Fasteners
- Head Style:
- Flat Countersunk Head
