- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- Pan head screws are also known as raised cheese head screws.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M4
- Thread Pitch: 0.7
- Diameter (Dimension): 4mm
- Length (Nominal): 6mm
- Thread Length (Nominal): 6mm
- Head Diameter: 8.5mm
- Head Diameter (Minimum): 8.28mm
- Head Diameter (Maximum): 8.5mm
- Head Height, Overall: 2.4mm
- Head Height, Overall (Minimum): 2.28mm
- Head Height, Overall (Maximum): 2.52mm
- Shoulder Diameter: 5.5mm
- Shoulder Diameter (Minimum): 5.47mm
- Shoulder Diameter (Maximum): 5.5mm
- Shoulder Length: 6mm
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Shoulder Under Head
- Head Style: Pan Head
- Drive Style: Slotted Drive
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: AISI 303 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 923
Product UPC Code:
692559678443
- Coating:
- Uncoated
- Head Height, Overall (Minimum):
- 2.28mm
- Shoulder Diameter (Minimum):
- 5.47mm
- System of Measurement:
- Metric
- Shop by System of Measurement:
- Metric
- Head Height, Overall:
- 2.4mm
- Standards and Specifications:
- DIN 923
- Head Diameter (Minimum):
- 8.28mm
- Thread Length (Nominal):
- 6mm
- Brand:
- Aspen Fasteners
- Shoulder Length:
- 6mm
- Material:
- Stainless Steel
- POS:
- ME516-407X6-000100
- Head Diameter (Maximum):
- 8.5mm
- Drive Style:
- Slotted Drive
- Head Style:
- Pan Head
- Shoulder Diameter:
- 5.5mm
- Material Grade:
- AISI 303 Stainless Steel
- Thread Pitch:
- 0.7
- Thread Direction:
- Right-Hand Thread
- Length (Nominal):
- 6mm
- Head Height, Overall (Maximum):
- 2.52mm
- Shoulder Diameter (Maximum):
- 5.5mm
- Order:
- Machine Thread Fasteners
- Category:
- Machine Screws
- Head Diameter:
- 8.5mm
- Form and Design:
- Shoulder Under Head
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME516-407X6
- Shop by Material:
- Stainless Steel
- Diameter (Dimension):
- 4mm
- Diameter (Nominal):
- M4
- Product Class:
- Externally Threaded Fasteners
