- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- Oval countersunk head screws are also known as raised countersunk head screws.
- Class 4.8 steel is a low or medium carbon steel with a minimum tensile strength of 420N/mm-2 (Mpa).
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M5
- Thread Pitch: 0.8
- Diameter (Dimension): 5mm
- Length (Nominal): 14mm
- Thread Length (Nominal): 12.75mm
- Head Diameter: 9.2mm
- Head Diameter (Minimum): 8.84mm
- Head Diameter (Maximum): 9.2mm
- Head Height, Overall: 2.5mm
- Head Dome Height: 1.25mm
- Slot Depth (Minimum): 2mm
- Slot Depth (Maximum): 2.3mm
- Slot Width (Nominal): 1.2mm
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Oval Countersunk Head
- Head Style Detail: 90 Degree Countersink
- Drive Style: Slotted Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Class 4.8 Steel
- Coating: Zinc Plated
- Coating Color: Clear
- Origin: Origin Undefined
- Standards and Specifications: DIN 964 / ISO 2010
Product UPC Code:
698435208261
- Brand:
- Aspen Fasteners
- Category:
- Machine Screws
- Coating:
- Zinc Plated
- Coating Color:
- Clear
- Diameter (Dimension):
- 5mm
- Diameter (Nominal):
- M5
- Drive Style:
- Slotted Drive
- Head Diameter:
- 9.2mm
- Head Diameter (Maximum):
- 9.2mm
- Head Diameter (Minimum):
- 8.84mm
- Head Dome Height:
- 1.25mm
- Head Height, Overall:
- 2.5mm
- Head Style:
- Oval Countersunk Head
- Head Style Detail:
- 90 Degree Countersink
- Length (Nominal):
- 14mm
- Material:
- Steel
- Material Grade:
- Class 4.8 Steel
- Order:
- Machine Thread Fasteners
- Origin:
- Origin Undefined
- POS:
- ME197-508X14-00300
- Product Class:
- Externally Threaded Fasteners
- Slot Depth (Maximum):
- 2.3mm
- Slot Depth (Minimum):
- 2mm
- Slot Width (Nominal):
- 1.2mm
- Standards and Specifications:
- DIN 964 / ISO 2010
- System of Measurement:
- Metric
- Thread Direction:
- Right-Hand Thread
- Thread Length:
- Full Thread
- Thread Length (Nominal):
- 12.75mm
- Thread Pitch:
- 0.8
