- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- Class 4.8 steel is a low or medium carbon steel with a minimum tensile strength of 420N/mm-2 (Mpa).
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M5
- Thread Pitch: 0.8
- Diameter (Dimension): 5mm
- Length (Nominal): 55mm
- Thread Length (Nominal): 55mm
- Head Diameter: 8.5mm
- Head Diameter (Minimum): 8.28mm
- Head Diameter (Maximum): 8.5mm
- Head Height, Overall: 3.3mm
- Head Height, Overall (Minimum): 3.12mm
- Head Height, Overall (Maximum): 3.3mm
- Slot Depth (Nominal): 1.3mm
- Slot Width (Nominal): 1.2mm
- Slot Width (Minimum): 1.26mm
- Slot Width (Maximum): 1.51mm
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Head Style: Cheese Head
- Drive Style: Slotted Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Class 4.8 Steel
- Coating: Zinc Plated
- Coating Color: Clear
- Origin: Origin Undefined
- Standards and Specifications: DIN 84 / ISO 1207
Product UPC Code:
698435187450
- Head Height, Overall:
- 3.3mm
- Head Diameter:
- 8.5mm
- Length (Nominal):
- 55mm
- Thread Pitch:
- 0.8
- Diameter (Dimension):
- 5mm
- Diameter (Nominal):
- M5
- Standards and Specifications:
- DIN 84 / ISO 1207
- Coating Color:
- Clear
- Coating:
- Zinc Plated
- Material Grade:
- Class 4.8 Steel
- Material:
- Steel
- Thread Length:
- Full Thread
- Thread Direction:
- Right-Hand Thread
- Drive Style:
- Slotted Drive
- Head Style:
- Cheese Head
- Brand:
- Aspen Fasteners
- System of Measurement:
- Metric
- Category:
- Machine Screws
- Order:
- Machine Thread Fasteners
- Product Class:
- Externally Threaded Fasteners
- POS:
- ME132-508X55-00800
- Shop by System of Measurement:
- Metric
- Slot Width (Nominal):
- 1.2mm
- Thread Length (Nominal):
- 55mm
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME132-508X55.zip
- Head Diameter (Minimum):
- 8.28mm
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product64/ME132-508X55.PDF
- Shop by Material:
- Steel
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME132-508X55
- Slot Width (Minimum):
- 1.26mm
- Slot Width (Maximum):
- 1.51mm
- Slot Depth (Nominal):
- 1.3mm
- Head Diameter (Maximum):
- 8.5mm
- Origin:
- Origin Undefined
- Head Height, Overall (Minimum):
- 3.12mm
- Head Height, Overall (Maximum):
- 3.3mm
