- Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
- Pan head screws are also known as raised cheese head screws.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M8
- Thread Pitch: 1.25
- Diameter (Dimension): 8mm
- Length (Nominal): 12mm
- Thread Length (Nominal): 11mm
- Head Diameter: 16mm
- Head Diameter (Minimum): 15.73mm
- Head Diameter (Maximum): 16mm
- Head Height, Overall: 3.8mm
- Head Height, Overall (Minimum): 3.65mm
- Head Height, Overall (Maximum): 3.95mm
- Shoulder Diameter: 10mm
- Shoulder Diameter (Minimum): 9.964mm
- Shoulder Diameter (Maximum): 10mm
- Shoulder Length: 12mm
PRODUCT ATTRIBUTES- Category: Machine Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Shoulder Under Head
- Head Style: Pan Head
- Drive Style: Slotted Drive
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: AISI 303 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 923
Product UPC Code:
692559678719
- Head Diameter (Maximum):
- 16mm
- System of Measurement:
- Metric
- Coating:
- Uncoated
- Material Grade:
- AISI 303 Stainless Steel
- Shoulder Diameter (Minimum):
- 9.964mm
- POS:
- ME516-8125X12-000050
- Shoulder Diameter (Maximum):
- 10mm
- Drive Style:
- Slotted Drive
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME516-8125X12
- Diameter (Dimension):
- 8mm
- Form and Design:
- Shoulder Under Head
- Shoulder Diameter:
- 10mm
- Shop by System of Measurement:
- Metric
- Head Style:
- Pan Head
- Length (Nominal):
- 12mm
- Material:
- Stainless Steel
- Order:
- Machine Thread Fasteners
- Head Diameter:
- 16mm
- Category:
- Machine Screws
- Diameter (Nominal):
- M8
- Shop by Material:
- Stainless Steel
- Thread Pitch:
- 1.25
- Head Height, Overall:
- 3.8mm
- Head Height, Overall (Minimum):
- 3.65mm
- Thread Direction:
- Right-Hand Thread
- Brand:
- Aspen Fasteners(r)
- Head Diameter (Minimum):
- 15.73mm
- Product Class:
- Externally Threaded Fasteners
- Thread Length (Nominal):
- 11mm
- Head Height, Overall (Maximum):
- 3.95mm
- Standards and Specifications:
- DIN 923
- Shoulder Length:
- 12mm
