- Hex cap screws are manufactured to tighter tolerances as compared to hex bolts.
- A4-80 stainless steel provides a minimum tensile strength of 800N/mm-2 (Mpa).
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Washer face provides a precision bearing surface.
- Chamfered point improves engagement with a nut or pre-tapped hole.
- Diameter (Nominal): M16
- Thread Pitch: 2.0
- Diameter (Dimension): 16mm
- Length (Nominal): 45mm
- Thread Length: 38mm
- Across Flats (Basic): 24mm
- Head Height, Overall: 10mm
- Product Class: Externally Threaded Fasteners
- Order: Machine Thread Fasteners
- Category: Cap Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Hex Head
- Head Style Detail: Washer Face
- Drive Style: External Hex Drive
- Pitch: Coarse Thread
- Thread Length: Part Thread
- Thread Direction: Right-Hand Thread
- Point: Chamfered Point
- Material: Stainless Steel
- Material Grade: A4-80 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 931 / ISO 4014
- Buy 3 - 9 and get 10% off
- Buy 10 or above and get 20% off
- Across Flats (Basic):
- 24mm
- Shop by System of Measurement:
- Metric
- Shop by Material:
- Stainless Steel
- Product Class:
- Externally Threaded Fasteners
- Order:
- Machine Thread Fasteners
- Category:
- Cap Screws
- System of Measurement:
- Metric
- Brand:
- Aspen Fasteners(r)
- Head Style:
- Hex Head
- Head Style Detail:
- Washer Face
- Drive Style:
- External Hex Drive
- Pitch:
- Coarse Thread
- Thread Length:
- Part Thread
- Head Height, Overall:
- 10mm
- Thread Direction:
- Right-Hand Thread
- Point:
- Chamfered Point
- Material:
- Stainless Steel
- Material Grade:
- A4-80 Stainless Steel
- Coating:
- Uncoated
- Standards and Specifications:
- DIN 931 / ISO 4014
- Diameter (Nominal):
- M16
- Diameter (Dimension):
- 16mm
- Thread Pitch:
- 2.0
- Length (Nominal):
- 45mm
- Thread Length:
- 38mm
Buy in bulk and save
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
-
Description
- Hex cap screws are manufactured to tighter tolerances as compared to hex bolts.
- A4-80 stainless steel provides a minimum tensile strength of 800N/mm-2 (Mpa).
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Washer face provides a precision bearing surface.
- Chamfered point improves engagement with a nut or pre-tapped hole.
- Diameter (Nominal): M16
- Thread Pitch: 2.0
- Diameter (Dimension): 16mm
- Length (Nominal): 45mm
- Thread Length: 38mm
- Across Flats (Basic): 24mm
- Head Height, Overall: 10mm
- Product Class: Externally Threaded Fasteners
- Order: Machine Thread Fasteners
- Category: Cap Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Head Style: Hex Head
- Head Style Detail: Washer Face
- Drive Style: External Hex Drive
- Pitch: Coarse Thread
- Thread Length: Part Thread
- Thread Direction: Right-Hand Thread
- Point: Chamfered Point
- Material: Stainless Steel
- Material Grade: A4-80 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 931 / ISO 4014
- Product UPC Code:
- 698435850217
