M2.5-0.45 DIN 985, Metric, Hex Nylon Insert Stop Lock Nuts, A2 Stainless Steel

M2.5-0.45 DIN 985, Metric, Hex Nylon Insert Stop Lock Nuts, A2 Stainless Steel

PART NUMBER:
ME223-25045X38X5-001500
Free Shipping Free ground shipping to the 48 contiguous US states.
Normal delivery time 2-3 days.
For more information, visit our Shipping and Deliveries page.
(No reviews yet) Write a Review
PACK QUANTITY PRICE PER PACK Availability SELECT NUMBER OF PACKS Add to cart
question By saving items to your Saved Items lists, you can quickly and easily organize and retrieve the parts that are important to you. Your can create and name as many lists as you require and add as many parts as you need to each of your lists.
  • Also known as elastic stop nuts, this self locking nut uses a nylon collar that resists turning.
  • The nylon insert collar retains its locking ability up to 250 degrees F (121 degrees C).
  • A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
  • Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES
  • Diameter (Nominal): M2.5
  • Thread Pitch: 0.45
  • Diameter (Dimension): 2.5mm
  • Across Flats (Basic): 5mm
  • Across Flats (Minimum): 4.78mm
  • Across Flats (Maximum): 5mm
  • Height (Basic): 3.8mm
  • Height (Minimum): 3.5mm
  • Height (Maximum): 3.8mm
PRODUCT ATTRIBUTES
  • Category: Hex Nylon Insert Stop Lock Nuts
  • System of Measurement: Metric
  • Brand: Aspen Fasteners®
  • Drive Style: External Hex Drive
  • Thread Length: Full Thread
  • Thread Direction: Right-Hand Thread
  • Material: Stainless Steel
  • Material Grade: A2 Stainless Steel
  • Coating: Uncoated
  • Standards and Specifications: DIN 985
Across Flats (Basic):
5mm
Brand:
Aspen Fasteners(r)
Height (Minimum):
3.5mm
POS:
ME223-25045X38X5-001500
Order:
Lock Nuts
Height (Maximum):
3.8mm
Thread Length:
Full Thread
specifications_document_url:
https://www.aspenfasteners.com/content/2D_PDF/product98/ME223-25045X38X5.PDF
Diameter (Nominal):
M2.5
Material:
Stainless Steel
Coating:
Uncoated
Height (Basic):
3.8mm
Drive Style:
External Hex Drive
Shop by System of Measurement:
Metric
Product Class:
Internally Threaded Fasteners
Shop by Material:
Stainless Steel
Diameter (Dimension):
2.5mm
Across Flats (Minimum):
4.78mm
System of Measurement:
Metric
cad_3d_file_url:
https://3d.aspenfasteners.com/assets/obj/ME223-25045X38X5.zip
Material Grade:
A2 Stainless Steel
Category:
Hex Nylon Insert Stop Lock Nuts
Standards and Specifications:
DIN 985
Across Flats (Maximum):
5mm
Thread Pitch:
0.45
Thread Direction:
Right-Hand Thread
cad_3d_viewer_url:
https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME223-25045X38X5
Copy Link
Print
  • Description
    • Also known as elastic stop nuts, this self locking nut uses a nylon collar that resists turning.
    • The nylon insert collar retains its locking ability up to 250 degrees F (121 degrees C).
    • A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
    • Stainless steel significantly improves resistance to tarnishing or corrosion.
    DIMENSIONAL ATTRIBUTES
    • Diameter (Nominal): M2.5
    • Thread Pitch: 0.45
    • Diameter (Dimension): 2.5mm
    • Across Flats (Basic): 5mm
    • Across Flats (Minimum): 4.78mm
    • Across Flats (Maximum): 5mm
    • Height (Basic): 3.8mm
    • Height (Minimum): 3.5mm
    • Height (Maximum): 3.8mm
    PRODUCT ATTRIBUTES
    • Category: Hex Nylon Insert Stop Lock Nuts
    • System of Measurement: Metric
    • Brand: Aspen Fasteners®
    • Drive Style: External Hex Drive
    • Thread Length: Full Thread
    • Thread Direction: Right-Hand Thread
    • Material: Stainless Steel
    • Material Grade: A2 Stainless Steel
    • Coating: Uncoated
    • Standards and Specifications: DIN 985
  • 3D Product View

Contact us for availability information on part number ME223-25045X38X5-001500. Please chat with us, call us, e-mail us, or use the form below. Our customer support team will find the best delivery options for you.
