M8-1.0 DIN 934 / ISO 4032, Metric, Hex Finished Nuts, Class 8 Steel, Yellow Zinc Plated

PART NUMBER:
ME181-810-00600
Free Shipping Free ground shipping to the 48 contiguous US states.
Normal delivery time 2-3 days.
For more information, visit our Shipping and Deliveries page.
(No reviews yet) Write a Review
PACK QUANTITY PRICE PER PACK Availability SELECT NUMBER OF PACKS Add to cart
question By saving items to your Saved Items lists, you can quickly and easily organize and retrieve the parts that are important to you. Your can create and name as many lists as you require and add as many parts as you need to each of your lists.
  • Hex finished nuts are considered the most commonly used hex nuts.
  • DIN 934 hex nuts are the most commonly used metric hex nuts.
  • Also known as regular hex nuts.
  • Class 8 nuts are designed to be used with screws and bolts of property class 8.8 or lower.
DIMENSIONAL ATTRIBUTES
  • Diameter (Nominal): M8
  • Thread Pitch: 1.0
  • Diameter (Dimension): 8mm
  • Thread Length (Nominal): 6.5mm
  • Across Flats (Basic): 13mm
  • Across Flats (Minimum): 12.73mm
  • Across Flats (Maximum): 13mm
  • Height (Basic): 6.5mm
  • Height (Minimum): 6.14mm
  • Height (Maximum): 6.5mm
  • Washer Face Diameter (Minimum): 11.3mm
PRODUCT ATTRIBUTES
  • Category: Hex Finished Nuts
  • System of Measurement: Metric
  • Brand: Aspen Fasteners
  • Drive Style: External Hex Drive
  • Thread Length: Full Thread
  • Thread Direction: Right-Hand Thread
  • Material: Steel
  • Material Grade: Class 8 Steel
  • Coating: Zinc Plated
  • Coating Color: Yellow
  • Standards and Specifications: DIN 934 / ISO 4032
Product UPC Code:
698435200142
Across Flats (Maximum):
13mm
Diameter (Dimension):
8mm
POS:
ME181-810-00600
Shop by System of Measurement:
Metric
cad_3d_viewer_url:
https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME181-810
Thread Length (Nominal):
6.5mm
Thread Pitch:
1.0
Height (Maximum):
6.5mm
Order:
Nuts
Material:
Steel
System of Measurement:
Metric
Thread Direction:
Right-Hand Thread
Brand:
Aspen Fasteners
Coating Color:
Yellow
Shop by Material:
Steel
Across Flats (Minimum):
12.73mm
Category:
Hex Finished Nuts
specifications_document_url:
https://www.aspenfasteners.com/content/2D_PDF/product37/ME181-810.PDF
cad_3d_file_url:
https://3d.aspenfasteners.com/assets/obj/ME181-810.zip
Height (Minimum):
6.14mm
Drive Style:
External Hex Drive
Diameter (Nominal):
M8
Across Flats (Basic):
13mm
Standards and Specifications:
DIN 934 / ISO 4032
Product Class:
Internally Threaded Fasteners
Thread Length:
Full Thread
Coating:
Zinc Plated
Material Grade:
Class 8 Steel
Height (Basic):
6.5mm
  • Description
    • Hex finished nuts are considered the most commonly used hex nuts.
    • DIN 934 hex nuts are the most commonly used metric hex nuts.
    • Also known as regular hex nuts.
    • Class 8 nuts are designed to be used with screws and bolts of property class 8.8 or lower.
    DIMENSIONAL ATTRIBUTES
    • Diameter (Nominal): M8
    • Thread Pitch: 1.0
    • Diameter (Dimension): 8mm
    • Thread Length (Nominal): 6.5mm
    • Across Flats (Basic): 13mm
    • Across Flats (Minimum): 12.73mm
    • Across Flats (Maximum): 13mm
    • Height (Basic): 6.5mm
    • Height (Minimum): 6.14mm
    • Height (Maximum): 6.5mm
    • Washer Face Diameter (Minimum): 11.3mm
    PRODUCT ATTRIBUTES
    • Category: Hex Finished Nuts
    • System of Measurement: Metric
    • Brand: Aspen Fasteners
    • Drive Style: External Hex Drive
    • Thread Length: Full Thread
    • Thread Direction: Right-Hand Thread
    • Material: Steel
    • Material Grade: Class 8 Steel
    • Coating: Zinc Plated
    • Coating Color: Yellow
    • Standards and Specifications: DIN 934 / ISO 4032
    Product UPC Code:
    698435200142
